MRH-P Series Methanol-to-Hydrogen System

FD38(T) Diesel Forklift
Details:

The MRH-P series methanol reforming hydrogen production system delivers 99.999% high-purity hydrogen for applications with relatively large hydrogen demand. Hydrogen output ranges from 200 to 500 Nm³/h. The equipment generates hydrogen on site, replacing tube-trailer purchased hydrogen, addressing long-distance storage and transportation at the source and significantly reducing the overall cost of hydrogen at the point of use. The complete unit adopts a skid-mounted, explosion-proof integrated design, combining a methanol reforming unit, a PSA purification unit, an explosion-proof automatic control system, a circulating cooling-water system, and a fuel blending system. Installation is straightforward, and operation is safe and stable.

Send Inquiry
Product Features
  • 01

    H₂ purity: 99.999%

  • 02

    Skid-mounted, compact

  • 03

    Stable PSA hydrogen

  • 04

    15-year service life

General Technical Specifications
ParameterSpecification
Hydrogen purity≥99.999% (vol)
Outlet pressure≤1.3 MPaG
Dew point-73°C
Hydrogen temperature≤40°C
Equipment service life15 years
Flow turndown range30%–110%
Hydrogen purificationSingle-stage PSA
Model Specifications
ModelMethanolTap water
Operating powerInstalled power
Cooling waterInstrument airDimensions
Nm³/hkg/hL/hkWkWt/hNm³/hmm
2008796
1838.51010H2 system: 10200×3150×3430
Heating: 7300×2400×2725
2501401503038.51510H2 system: 12000×3350×3430
Heating: 7300×2400×2725
350196
21036.75601515H2 system: 12450×3540×3770
Heating: 7800×2400×2725
40022424042652015H2 system: 12450×3540×3970
Heating: 7800×2400×2725
50028030050652015H2 system: 13650×3540×3970
Heating: 7800×2400×2725
Note: Hydrogen production system supplied as an EPC package, covering engineering design, supply, on-site installation, technical services, and training for the hydrogen production system, PSA purification, explosion-proof control, cooling-water, blending, demineralized-water, and heating systems. Dimensions are for reference only; actual dimensions may vary with production and shall be based on the delivered product.
